H01
H02F
H04
H08M
V12
H24S
As your reliable business collaborator, we provide exceptional supply capabilities. Rely on us to provide FUJI NXT Placing Heads whenever required, ensuring production continuity.
Our guarantee is prompt delivery.Typically, the lead time is between one and three days, and we assure timely delivery to keep your production line running smoothly.
Our assistance extends beyond mere delivery. We provide comprehensive post-sale support, ensuring that FUJI NXT Placing Heads are seamlessly integrated and operated. Your tranquility is paramount.
As your dependable business partner, we offer multifaceted solutions to meet all of your production requirements. Whatever your needs may be, we are prepared to assist you.
Aligning with your needs, our warehouse holds a comprehensive inventory of FUJI Placing Heads, poised to support your production requirements.
Is your FUJI NXT Placing Head malfunctioning? Finding FUJI engineers for repairs can be costly. Why not consider us for repairs? With our skilled technicians, reasonable prices, and swift turnaround, repairing no longer burdens you. We offer comprehensive repair assurance, ensuring your FUJI Placing Head maintains optimal performance, freeing you from any concerns.
| M3 III | M6 III | |||
| Placement accuracy (Fiducial mark standard) * The placing accuracy is obtained from tests conducted by Fuji. |
H24G | +/-0.025 mm (Standard mode) / +/-0.038 mm (Productivity priority mode) (3sigma) cpk≥1.00 | H24G | +/-0.025 mm (Standard mode) / +/-0.038 mm (Productivity priority mode) (3sigma) cpk≥1.00 |
| V12/H12HS | +/-0.038 (+/-0.050) mm (3sigma) cpk≥1.00 | V12/H12HS | +/-0.038 (+/-0.050) mm (3sigma) cpk≥1.00 | |
| H04S/H04SF | +/-0.040 mm (3sigma) cpk≥1.00 | H08M/H04S/H04SF | +/-0.040 mm (3sigma) cpk≥1.00 | |
| H08/H04 | +/-0.050 mm (3sigma) cpk≥1.00 | H08/H04/OF | +/-0.050 mm (3sigma) cpk≥1.00 | |
| H02/H01/G04 | +/-0.030 mm (3sigma) cpk≥1.00 | H02/H01/G04 | +/-0.030 mm (3sigma) cpk≥1.00 | |
| H02F/G04F | +/-0.025 mm (3sigma) cpk≥1.00 | H02F/G04F | +/-0.025 mm (3sigma) cpk≥1.00 | |
| GL | +/-0.100 mm (3sigma) cpk≥1.00 | GL | +/-0.100 mm (3sigma) cpk≥1.00 | |
| Productivity * The throughput above is based on tests conducted at Fuji. |
H24G | 37,500 cph (Productivity priority mode) / 35,000 cph (Standard mode) | H24G | 37,500 cph (Productivity priority mode) / 35,000 cph (Standard mode) |
| V12 | 26,000 cph | V12 | 26,000 cph | |
| H12HS | 24,500 cph | H12HS | 24,500 cph | |
| H08 | 11,500 cph | H08M | 13,000 cph | |
| H04 | 6,500 cph | H08 | 11,500 cph | |
| H04S | 9,500 cph | H04 | 6,500 cph | |
| H04SF | 10,500 cph | H04S | 9,500 cph | |
| H02 | 5,500 cph | H04SF | 10,500 cph | |
| H02F | 6,700 cph | H02 | 5,500 cph | |
| H01 | 4,200 cph | H02F | 6,700 cph | |
| G04 | 7,500 cph | H01 | 4,200 cph | |
| G04F | 7,500 cph | G04 | 7,500 cph | |
| GL | 16,363 dph (0.22 sec/dot) | G04F | 7,500 cph | |
| Supported parts | H24G | 0201 to 5 x 5 mm | Height | up to 2.0 mm |
| V12/H12HS | 0402 to 7.5 x 7.5 mm | Height | up to 3.0 mm | |
| H08M | 0603 to 45 x 45 mm | Height | up to 13.0 mm | |
| H08 | 0402 to 12 x 12 mm | Height | up to 6.5 mm | |
| H04 | 1608 to 38 x 38 mm | Height | up to 9.5 mm | |
| H04S/H04SF | 1608 to 38 x 38 mm | Height | up to 6.5 mm | |
| H02/H02F/H01/0F | 1608 to 74 x 74 mm (32 x 180 mm) | Height | up to 25.4 mm | |
| G04/G04F | 0402 to 15 x 15 mm | Height | up to 6.5 mm | |
FUJI pick and place machine and parts. Our products are sold all over the world with high quality, fast response, and unmatched delivery speed. We guarantee that we will offer you the most professional machine tool and fulfill your requirements.
FUJI Placement machines:
CP series: CP6, CP7, CP8 etc.
XP series: XP141, XP142, XP143, XP143E, etc.
QP series: QP132, QP142, QP143, QP242, QP341
NXT series: NXT I, NXT II, NXT III.
Accessories include：Feeder , Nozzle, Motor , Board , holder , filter , Valle, Sensor, etc.
Repair Services: We provide maintenance services: mainly FUJI placement head, Driver , Motor , Board.
| Part Number Part Name DescriptionFunction Used2AGKBA0016CPU BoxPDS-BX01S1065Auto Head Cleaner2AGMBA0070CPU Box AIMEX, AIMEX II/IIS2AGMBA0071CPU Box AIMEX, AIMEX II/IIS2AGMZZ0001CPU BoxFor ModuleAIMEX2AGMZZ0002CPU BoxFor BaseAIMEX2AGPBA0062CPU Box NXTP-M25/M352AGTBC0018CPU BoxPDS-BX01S1069NXT III/IIIc2AGTBC0029CPU BoxPDS-BX01S1108NXT III M6IIIL2AGTBC0054CPU BoxPDS-BX05S1069 (without SRAM)NXT III/IIIc (software Ver: V7.80 or later)2AGWBA0108CPU BoxPDS-BX03S1219NXT-H, MWU12i2AHFBA0159CPU Box AIMEX III,AIMEX IIIc single robot2AHFBA0160CPU Box AIMEX III,AIMEX IIIc twin robot2EGWBA0651CPU Board NXT-H |
We have a variety of express delivery options for your goods, such as DHL, UPS and FedEx Express. We deliver using the quickest and cheapest way, or with the best transportation resources according to the cargo weight, volume and so on.You can relax, we will do our best to deliver your packages quickly and safely, no matter by which mode of transportation.
About payment, we accept multiple payment methods, such as T/T, Paypal, Western Union, Alipay and WeChat. Any kind of payment is official. Once your order is confirmed, we will send a photo to you as a reference before shipping.
Your goods are handled with great care from the time of purchase to delivery. After going through QA inspection, we use foam cotton and pearl cotton to wrap each piece of product so that it arrives at your hand in perfect condition. The vacuum bags & wooden boxes we use for packing our equipment are carefully selected to ensure no rust occurs during shipment by sea, which can cause serious damage to your equipment.
We provide a full range of SMT equipment and spare parts including Samsung, Panasonic, Fuji, JUKI, YAMAHA, etc., and also provide customers with high-quality smt equipment and parts services.
