Elevate your production line with our cutting edge SMT solutions, where precision meets productivity. At the core of our offering is the pick and place machine, engineered to place thousands of components per hour with micron level accuracy. Whether you’re prototyping new designs or scaling up full volume manufacturing, our robust, easy to program systems ensure consistent quality and maximum uptime empowering you to meet tight deadlines and demanding tolerances every time.
Showing 1–16 of 76 results
An SMT pick and place machine is a highly automated piece of equipment used in modern electronics manufacturing to place surface-mount devices onto printed circuit boards (PCBs) with exceptional speed and accuracy. By integrating precision vacuum nozzles, programmable vision systems, and adjustable feeders, these machines can handle a vast range of component sizes—from tiny 0201 resistors up to large QFP packages—without manual intervention. The result is consistent placement accuracy (often within ± 0.02 mm) and production rates that can exceed 10,000 components per hour, making SMT pick and place machines indispensable for both prototyping and high-volume runs.
A pick ’n’ place machine follows a logical sequence of steps to automate PCB assembly:
Component Feeding: Tape-and-reel or tray feeders present components to the machine.
Vision & Alignment: High-resolution cameras scan fiducials on the PCB and verify component orientation.
Pick-Up: Precision vacuum nozzles “pick” parts from the feeder, guided by the vision system.
Placement: The head moves along X-Y axes to the correct position on the PCB, then gently “places” the part.
Verification: A post-placement vision check ensures the component sits within spec before proceeding.
This coordinated workflow—driven by intuitive software and real-time feedback—enables pick ’n’ place machines to achieve high throughput, exceptional repeatability, and minimal setup times between different product runs.
Desktop pick and place machines are compact, cost-effective systems designed for low- to mid-volume production and prototyping environments. These benchtop units typically feature one or two placement heads, limited feeder capacity, and user-friendly software, making them ideal for startups, R&D labs, and small electronics workshops. Despite their smaller footprint, today’s desktop models can still achieve respectable speeds (often 1,000–3,000 CPH) and support a range of component sizes from 0402 up to QFP packages.
Automated pick and place machines represent the next step up in throughput and flexibility, with multi-head placement gantries, automatic tool changers, and high-capacity feeders. These systems can handle tens of thousands of components per hour, dynamically switch between different nozzle types, and integrate inline with solder paste printers and reflow ovens for a seamless SMT line. Their advanced vision systems ensure precise alignment and placement even at high speeds, making automated pick and place machines the backbone of large-scale PCB assembly operations.
SMD pick and place machines specialize in handling surface-mount devices (SMDs) across a broad spectrum of shapes—from tiny 0201 resistors to large BGAs. Variants include high-mix systems optimized for frequent changeovers, micro-component models with ultra-fine placement accuracy, and dual-lane machines that double throughput without expanding the footprint. Many SMD-focused machines also offer modular feeder configurations and customizable belt-feed options to accommodate odd-form parts and specialized components.
PCB pick and place machines are engineered to place components directly onto rigid or flexible circuit boards with absolute precision. Model choices range from entry-level inline units that integrate easily into existing lines to advanced gantry systems with multi-axis motion control and vacuum sealing for dust-free placement. When evaluating a pick and place PCB machine, consider board size compatibility, placement speed (CPH), nozzle interchangeability, and software features such as CAD import and real-time placement monitoring.
Understanding SMT machine cost is crucial when budgeting for your production line. Entry-level desktop pick and place machines can start as low as $5,000–$10,000, making them accessible for prototyping and low-volume runs. Mid-range standalone systems with higher feeder capacity and dual heads typically range from $20,000–$50,000. Fully automated, high-speed SMT lines—complete with inline solder paste printers, reflow ovens, and smart feeders—can exceed $100,000. Pricing varies based on placement speed (CPH), component range, vision-system sophistication, and software capabilities. Always request a detailed quote that breaks down hardware, software licenses, warranties, and optional accessories to compare smt machine price apples-to-apples.
Beyond the sticker price, calculate the total cost of ownership (TCO) to understand long-term value. TCO factors include:
Maintenance & Service Contracts: Annual calibration, software updates, and spare parts.
Consumables: Nozzles, tapes, and cleaning supplies.
Operator Training: Time and resources to train staff on new systems.
Downtime Costs: Lost production during changeovers or repairs.
Energy Consumption: Power usage of high-speed gantry drives and vacuum pumps.
In a competitive pick place machine market, vendors who offer bundled service packages, remote diagnostics, and software upgrades may reduce your TCO significantly—even if their initial price is higher.
Purchasing used surface mount equipment or refurbished pick and place machines can yield substantial savings—often 30–50% below new-unit pricing—without sacrificing quality. When evaluating smt machines for sale, look for:
Certification & Testing Reports: Proof of alignment accuracy and throughput.
Warranty Options: Coverage periods and service-level agreements.
Spare Parts Availability: Ease of sourcing nozzles and feeders.
Upgrade Paths: Ability to retrofit vision systems or add feeders later.
If your production needs are well-defined and unlikely to change rapidly, a certified refurbished pick and place machine can maximize ROI. However, for future-proofing and full support, a brand-new SMT system often provides better software integration and longer manufacturer warranties.
When choosing a pick and place machine, established manufacturers offer proven reliability, strong support, and continuous innovation. Key players include:
ASM Assembly Systems, known for ultra-high-speed heads and multi-lane configurations
Panasonic Factory Solutions, offering modular lines with advanced camera alignment
Yamaha Motor IM, featuring precision robotic arms and intuitive programming
JUKI Corporation, delivering compact machines with fast changeovers
Hanwha Precision Machinery, providing rugged systems with high feeder capacity
FUJI Corporation, excelling in micro-component placement and smart nozzle changers
Compare each vendor’s throughput, component mix capabilities, and service offerings to find the best fit for your production goals.
Beyond direct OEM sales, distributors play a crucial role in local support, training, and spare-parts logistics. Consider these channels:
Global electronics distributors that carry multiple brands and offer quick-turn demos
Regional system integrators who bundle pick and place machines with stencil printers and reflow ovens
Specialized used equipment suppliers stocking certified pre-owned machines with accuracy reports
Working with a knowledgeable distributor can shorten lead times, simplify installation, and ensure your pick and place machine remains productive for years.
Pick and place machines deliver unmatched speed and accuracy compared to manual assembly. By automating component placement, these systems reduce errors and improve yield, allowing your production line to operate at higher throughput with minimal rework. Consistent placement accuracy ensures that even fine-pitch and micro components are seated correctly on the PCB, reducing the risk of failures in the field. In addition, the programmable nature of modern machines makes changeovers fast and repeatable, so you can switch between different board designs without lengthy downtime. Investing in pick and place machines not only accelerates production but also lowers labor costs and enhances overall manufacturing quality.
SMT pick and place equipment is versatile enough to serve a variety of sectors. In consumer electronics, these machines assemble smartphones, tablets, and wearable devices where compact components and high volume demand precision. The automotive industry relies on them for electronic control units and sensor modules, where reliability under harsh conditions is critical. Telecommunications hardware such as routers and switches benefits from rapid, accurate assembly of densely packed boards.
In medical devices and aerospace, strict quality standards and traceability requirements make automated placement essential. Even small-batch prototyping labs and educational institutions use this equipment to train engineers and develop new electronic designs. Whatever the application, SMT pick and place equipment streamlines production, ensures consistency, and scales with your needs.
What is a pick place machine used for?
A pick place machine automates the placement of surface-mount components onto PCBs, improving speed, accuracy, and repeatability in SMT assembly processes.
Where can I find pick and place machines for sale?
To learn more about our new and refurbished pick and place machines, please contact us here and our sales team will guide you through our available options.
Are used pick and place machines reliable?
Yes—certified used machines undergo thorough testing, calibration, and refurbishment to ensure they meet performance standards. If you’d like details or a quote, get in touch here.
Looking for a reliable pick and place machine for sale to boost your SMT throughput? Our catalog features both new and certified refurbished systems designed to suit every production requirement and budget. To explore available models, compare pricing, and request a custom quote, please visit our Contact Us page our team of experts is ready to help you find the perfect solution and get you up and running quickly.
